Undulator-Beamline U 49/2-PGM2 at Bessy II

Detaied information:
technical description of the U 49/2 - PGM2
Handout for the operation of the f U 49/2 - PGM2

Images of the U 49/2-PGM2 (click on the foto in order to magnify it)

Side View : Bright highlighted are the Switching Mirror Unit (SMU) with radiation screening (yellow) and grid and chmaber. The bright highlighted tubes in between serve only as connection in UHV conditions. Behind the end of the left part the exit slit and the experimental set-up are following (see next image).
Top View on the experimental set-up: The tube comming from left behind is the continuation of the upper image. At the end of the the experimental set-up and the data aquisition is shown.
