Equipment
| Laser processing center for laser beam welding and cutting Reis Robotics handling system with 15 kW fiber laser (Windows Media Video- 7.5 MB) |
| Laser processing center for laser beam welding and cutting as well as laser powder buildup welding for generative manufacturing Trumpf TruCell 7040 (TruFlow 5 kW and TruDisc 2 kW) |
| SLM machine with integrated powder preparation system SLM 125 from Realizer with 400 W fiber laser |
| Atomiser with air classifier (crucible volume 3.4 l, temperature max. 1750 °C) Blue Power AU 3000 from Indutherm |
| Industrial robot for automated joining and generation Kuka KR 30 HA with rotary tilting table |
| MIG-MAG/CMT system for welding and brazing Fronius TransPulsSynergic 3200 |
| TIG/E manual welder Fronius MagicWave 2200 |
| Extension for welding with non-transmitting arc Torch PMC plasma technology PW350 |
| Digital MIG-MAG welding power source LORCH SpeedPulse S8 |
| Submerged arc welding machine Kjellberg KA1-UP |
| High power TIG welding machine Kjellberg InFocus 1000 |
| Plasma blasting machine Kjellberg HiFocus 160 |
| MSG/coldArc welding system EWM Phoenix 522 coldArc EWM Phoenix 521 PROGRESS PULS coldArc |
| Equipment for plasma powder build-up welding SatteliteHettiger Starweld PTA150H |
| Servo-hydraulic resistance spot welding machine; alternating current Elektro-Schweißtechnik-Dresden GmbH TPSBM 2132 S |
| Servo-pneumatic resistance spot welding gun; medium frequency technology DÜRING X 100 ALU |
| Welding data recorder with measuring channels for current, voltage, force (current measuring range 3 steps: 2 kA, 20 kA and 200 kA) and integrated quality documentation SPATZ Multi04 |
| Electrode milling cutter |
| Machining center for impulse friction stir welding UNITECH FS 400 iTNC 530 |
| High-Temperature Furnace for Preheating and Sintering Nabertherm HT 16/17 |
| Equipment for clinching and punch riveting TOX Pressotechnik type CEC 08.00 |
| Fine spot welding machine for joining metal foils, screen cloth and thin sheets Wahlenmeier ROWA 2Z1P / 800A with micro spotter and micro roller seam welding head |
| Virtual education and training system with processes MSG, TIG and E-Hand ARC+ |
| Simulation and Test Center Gleeble 3500 |
| Integrated joining and testing device for mechanical joining walter+bai AG |
| Areal deformation measuring system Gom Aramis |
| Areal hardness testing center BAQUT100-V |
| Micro/small force hardness testing machine STRUERS DuraScan20 (HV0.01- HV10) |
| High frequency generator Hüttinger Elektronik GmbH & Co. KG AXIO5/450 T |
| Metallographic examinations with image analysis Light microscope Leica DM2500M Leica M80 stereo microscope |
| Metallographic sample preparation Wet separator STRUERS Discotm-6 Warm embedding STRUERS Citopress-1 Cold embedding Grindingand polishing unit STRUERS Tegramin-30 |
| Hydrogen analyzer JUWE H-mat225 |
| Thermography system, measuring range -4°C to +2000°C Vario CAM hr research |
| Drop tower CEAST 9350 |
| High speed camera PhotronFastcam SA5 with Cavilux HF laser illumination |
| Wear test stand Tribometer(pin-on-disc test and ball-on-disc test) |
| Measuring amplifier systems HBMQuantumX HBM MGCplussynchronous acquisition of welding parameters, temperature field and distortion also in connection with the high-speed camera |
| Corrosion test stands VLMCorrosion test cabinet type CCT1000-T MF HT Corrosion tests according to: DIN EN ISO 9227 DIN EN ISO 6270-2 VW PV 1210 METROHM Autolab PGSTAT 101 |
| MicroCT / 2D and 3D evaluation BRUKERSkyScan1172 |
| Laser beam and power measurement system PROMETEC UFF100 PROMETEC Lasermeter |
| Optical 3D shape measurement system GOM ATOS Core |
| Climate change test bench (temperature range -70 to +180) Vötsch VC4100 |
| Electrodynamic linear torsion test system for fatigue strength testing Instron ElectroPuls E10000 |
- General FE program ANSYS® with further developments for joining simulation
- Welding specific FE-program SYSWELD®
- Fast analytical programs for the calculation of temperature distribution during welding
- Own developments for gas diffusion during joining
